PRE-INSULATED HDPE PIPE (GOST00001278)

Discount Rate : %45 Discount
Price : ₺1.090,95(Vat included)
Discounted : ₺598,02(Vat included)
Total Stock : 20000
₺66,45 With install ments starting from

Pre-Insulated HDPE Pipe (PE100 + PUR + HDPE Jacket)

Lightweight, corrosion-free distribution pipes for chilled/low-temperature heating, potable water and geothermal applications. The PE100 service pipe is factory insulated with high-density polyurethane foam and protected by a durable HDPE outer jacket for fast, clean installation and long service life.

  • Service Pipe: PE100 (black with blue stripe), SDR11/SDR17 options
  • Insulation: CFC-free rigid PUR foam, low thermal conductivity
  • Outer Jacket: Smooth HDPE protective casing, UV-resistant
  • Delivery: Coils up to 50/100 m (small diameters) or straight 6/12 m lengths
  • Connections: Electrofusion or butt-weld fittings; jacket sleeves & shrink caps
  • Options: Tracer wire/pipe detection, temperature sensor pocket, leak-alarm wire
  • Applications: Chilled water, potable water, low-temp district heating, geothermal, agriculture

Typical Specifications

Material (core) PE100 HDPE
SDR / Pressure SDR11 (PN16) · SDR17 (PN10) – project based
Insulation Rigid PUR foam, λ ≤ 0.029 W/m·K (typ.)
Outer Jacket HDPE protective casing, black, UV-stabilized
Operating Range Up to ~60 °C water (application dependent)
Sizes DN/OD 32–160 mm (others on request)
Standards PE pipe to EN/ISO for water; insulation to relevant norms
SKU GOST00001278

Get a Fast Quote on WhatsApp

Related: Pre-Insulated Geothermal Pipes · Industrial Water Treatment

Corrosion Resistance

Before HDPE became widespread, metal pipes were commonly used. Metal pipes react chemically with the conveyed fluid or the environment, causing corrosion (rust). Over time, corrosion on the inner and outer surfaces reduces flow area, increases pressure losses, and lowers system efficiency. It also shortens service life and increases replacement cost.
HDPE pipes do not corrode and show minimal microbial growth, enabling long-life, efficient hydraulic systems.

Despite their flexibility, HDPE pipes are stiff and creep-resistant; sudden flow or pressure changes do not cause fatigue—fatigue resistance is high.

Temperature range: −50 °C to +60 °C (application dependent)
Estimated service life: 50–100 years under proper operating conditions.

Additional advantages

  • Low density: easy, economical transport and handling

  • Flexibility: better seismic performance

  • High abrasion/friction resistance; no rust

  • Chemical resistance to many acids, bases and salts

  • Simple joining methods (electrofusion, butt welding, etc.)

  • Good cost–performance

  • No interaction with water; no effect on taste, odor or appearance

  • Smooth bore → low friction, high flow

  • Resistant to biofilm build-up

  • Electrically non-conductive

  • Resistant to many organic solvents; caution with nitric acid

  • Environmentally friendly; recyclable
